Using Docker Containers for Microservices in a Django + React Setup

Modern web development is increasingly shifting toward microservices architecture, where applications are broken into smaller, manageable services. When combined with Docker, microservices become easier to build, deploy, and scale. In this blog, we’ll walk you through setting up Docker containers for a project using Django (as the backend) and React (as the frontend) following the microservices approach.

Why Use Microservices with Docker?

Before jumping into the setup, here’s why this combo is powerful:

• Scalability: Scale only the services that need more resources.
• Independent Deployment: Update and deploy each service separately.
• Environment Parity: Docker ensures consistency across development, testing, and production.
• Fault Isolation: Problems in one service won’t affect the others.

Project Structure

Here’s an overview of our project structure:

bashCopyEditproject-root/
├── backend/              # Django App
│   ├── manage.py
│   └── ...
├── frontend/             # React App
│   ├── package.json
│   └── ...
├── nginx/
│   └── default.conf
├── docker-compose.yml
├── backend/Dockerfile
├── frontend/Dockerfile
└── .env

Step 1: Dockerize the Django Backend

backend/Dockerfile

DockerfileCopyEditFROM python:3.11-slim

ENV PYTHONDONTWRITEBYTECODE 1
ENV PYTHONUNBUFFERED 1

WORKDIR /app

COPY requirements.txt /app/
RUN pip install --upgrade pip && pip install -r requirements.txt

COPY . /app/

CMD ["gunicorn", "projectname.wsgi:application", "--bind", "0.0.0.0:8000"]

requirements.txt

shellCopyEditDjango>=4.0,<5.0
gunicorn

Step 2: Dockerize the React Frontend

frontend/Dockerfile

DockerfileCopyEditFROM node:20-alpine as build

WORKDIR /app
COPY package.json ./
COPY package-lock.json ./
RUN npm install

COPY . ./
RUN npm run build

FROM nginx:alpine
COPY --from=build /app/build /usr/share/nginx/html
COPY nginx/default.conf /etc/nginx/conf.d/default.conf

Step 3: NGINX for Reverse Proxy

nginx/default.conf

nginxCopyEditserver {
  listen 80;

  location / {
    root /usr/share/nginx/html;
    index index.html;
    try_files $uri $uri/ /index.html;
  }

  location /api/ {
    proxy_pass http://backend:8000/;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
  }
}

Step 4: Docker Compose for Multi-container Setup

docker-compose.yml

yamlCopyEditversion: '3.9'

services:
  backend:
    build: ./backend
    container_name: django_backend
    env_file:
      - .env
    volumes:
      - ./backend:/app
    ports:
      - "8000:8000"
    depends_on:
      - db

  frontend:
    build: ./frontend
    container_name: react_frontend
    ports:
      - "3000:80"
    depends_on:
      - backend

  db:
    image: postgres:15
    container_name: postgres_db
    restart: always
    volumes:
      - pgdata:/var/lib/postgresql/data
    environment:
      POSTGRES_DB: mydb
      POSTGRES_USER: myuser
      POSTGRES_PASSWORD: mypass

volumes:
  pgdata:

Step 5: Running the Stack

With all files in place, spin up your containers:

bashCopyEditdocker-compose up --build

This will:

• Build and start your Django backend on port 8000
• Build and serve your React frontend on port 3000
• Start a PostgreSQL database service
• Use NGINX to reverse proxy requests

Best Practices for Microservices with Docker

• Use .env files to keep secrets and environment variables secure.
• Separate services: As your project grows, consider splitting services like auth, payments, and notifications into independent Django apps or separate repositories.
• CI/CD integration: Automate container builds and deployments.
• Health checks: Add healthcheck configurations in docker-compose.yml for better reliability.

Conclusion

Using Docker to containerize a Django + React microservices architecture brings consistency, scalability, and ease of deployment to your development process. With docker-compose, you can run your full-stack application locally or in production environments with minimal configuration changes.
